Heavy Duty Towball 3,500kg - E Approved

Heavy Duty Towball 3,500kg - E Approved

Without Bolts
$17.27
$17.27 $24.33
Skip to product information
Heavy Duty Towball 3,500kg - E Approved
  • Heavy Duty Towball 3,500kg - E Approved
  • Heavy Duty Towball 3,500kg - E Approved
Heavy Duty Towball 3,500kg - E Approved

Heavy Duty Towball 3,500kg - E Approved

$17.27
$17.27 $24.33
Towball

    FREE DELIVERY ON ALL UK MAINLAND ORDERS

    • Heavy duty 3,500kg towball

      Specifications:
      Height: 120mm
      Width: 140mm
      Depth: 100mm
      Mounting Hole Centre: 90mm
      Fixing Holes:  M16 Dia.
      D Value: 17.2kN
      S Value: 350kg
    • Standard 90mm fixing centres
    • 2 x M16 mounting bolt fixing holes
    • E approved to Reg 55
    • Approval No: E11 55R-0110512

    • UN/ECE Regulation 55 has been introduced to replace EC94/20 towbar regulation. Regulation 55 is fundamentally similar to EC94/20, but with additional test and administration requirements.

    • All of our towballs and ball & pin hitches are approved to Reg 55.

      Fitting Instructions

      • Use only BS3692 grade 8.8 H.T. bolts with lock washers
      • Torque to 240 Nm
      • Check torque again after first use and regularly thereafter
